Memory Game Electronics Kit

Includes all components required to build the Memory Game:

• Printed circuit board
• STC15W408AS MCU
• DIP-28 IC socket
• 2-digit, 7-segment LED display (x2)
• 0.5W 8Ω speaker
• Sound chip
• 7550-1 voltage regulator
• S8550 transistor
• S9013 transistor
• 5 mm Straw hat coloured LED (x4)
• Capacitors:
  - 10 µF electrolytic
  - 470 µF electrolytic
  - 104 ceramic
• 1N4148 diode
• Resistors:
  - 100 Ω (x8)
  - 10 kΩ (x2)
• 9V battery connector
• Memory game case (1 set)
• Silicone keys (x4)
• 7 mm self-tapping screws (x4)

Refer to the image gallery for photographs of each component.

Electronics & Circuitry Basics: Learn about resistors, capacitors, LEDs, diodes, and transistors. Study the detailed instruction manual and the circuit diagram to learn what each component does and how they all work together to produce the memory game.

Microcontroller Fundamentals: Discover how a programmed chip controls LEDs, sounds, and gameplay logic. Learn about feedback loops in electronics.

Practical Soldering Skills: Gain confidence with through-hole soldering, plus one relatively easy-to-solder SMD component—this serves as a great introduction to working with SMD components, which are prevalent in today's electronic devices.

Memory Training: After you've had the fun of building the game, use it to strengthen your memory recall and pattern recognition abilities with progressively harder sequences—up to 99 levels.

STEM in Action: See how coding, hardware, and logic combine to create a complete interactive device. This is an excellent foundation for learning how all electronics devices work.

Problem-Solving & Troubleshooting: Build resilience by identifying and fixing soldering issues or component placement issues that might arise during assembly. The sense of achievement from diagnosing and resolving an electronics problem is one of the most satisfying feelings you can have!

Cognitive Benefits: Improve focus, attention span, and mental agility while playing the memory game.

Show-and-Tell Ready: Create something impressive you can bring to class, clubs, or workshops. Your friends will be amazed when you tell them you built it yourself from simple parts!

Q: What makes this different from other STEM Electronics kits?
A: Unlike simple “build-and-done” kits, this one gives you a fully functional game you can play again and again. It combines electronics learning with real cognitive training and many hours of entertainment—train your brain while you have fun!

Q: How many levels does the game have?
A: Up to 99 levels of difficulty, with the game remembering your best score. Each level adds one more light to the sequence. Can you beat level 99? Challenge your family and friends—set your highest score and challenge anyone to beat it.

Q: Do I need to write code for this kit?
A: No, the MCU comes the code pre-installed to run the game functions and logic. Advanced electronics hobbyists can reprogram the code on the MCU if they have the right tools, knowledge, and experience.

Q: Is this suitable for beginners?
A: Yes! Most components are easy through-hole parts. Just follow our detailed instruction manual which has photographs and descriptions of every step. There’s one SMD component included to introduce learners to more advanced soldering. However, as SMD components go, this one is pretty easy to solder with connection points well spaced out and large enough to see with your unaided eyes.

Q: Where can I use this kit?
A: It’s great for STEM classrooms, homeschool projects, science fairs, maker clubs, and family bonding.

Q: What’s the gameplay like?
A: Four buttons light up in different colours in a random sequence. You must repeat the sequence correctly. Each level adds another step, making it harder as you progress. In addition to lighting up, each sequence also produces sounds. Therefore, you can train both your visual memory and your hearing memory!

Q: Can the game save my high score?
A: Yes! It stores your all-time best score so you can keep challenging yourself—or compete with friends. You also have the option of resetting the game back to level 1 at any time.

Dimensions (approx., when completed):

• Length: 10.3 cm
• Width: 6.5 cm
• Height (including buttons): 2.8 cm
• Weight (including battery): 129 grams

PCB Type: Mostly through-hole components, one SMD component (easy to solder).

Case material: ABS.

Keys material: Silicone.

Displays (x2): High score & Current score.

Audio: Built-in speaker and sound chip.

Power Supply: 9V DC battery (not included, widely available in any shop that sells batteries).

Power saving: Auto power off feature.

Anyone can build this Memory Game Electronics kit following our detailed step-by-step instruction manual which can be downloaded from the link below. The password to open the manual was sent to the same email that you placed your order from. Can't find it? Just Contact Us!

Download: Memory Game Electronics Kit Instruction Manual

Skill Level: Beginner - Intermediate
Age Rating: 12+ (adult supervision required for under 16's)
Assembly Time: Typically 2-4 hours

Tools required for this kit

• Soldering iron
• Solder wire

We sell these items as a bundle for just €25.95 (or currency equivalent) which saves 10 percent! Just click the link below to select your countries plug type and add to your order.

SOLDERING IRON & WIRE BUNDLE

Of course, you only need to buy the tools once; you'll use them again and again for your future electronics projects!
